Options Included:

J1A: Gravity/Gray/Kool Kiwi

1GD: Exterior Graphics – Delete

33E: Silver Forest

555: Wheels-Performance Stylized

8FV: Mercedes Chassis Upgrade PKG

85Y: Radio/Rear View Mon. System

44E

Length: 19’5″

Exterior Height: 19’10”

Exterior Width: 7’1″

Awning Length: 10′

Interior Height: 6’3″

Interior Width: 6’7″

Freshwater Tank Capacity (gal.) 21

Water Heater Capacity (gal.) Continuous

Cassette Toilet Capacity (gal.) 5

Holding Tank Capacity – Gray (gal.) 21

LP Capacity (gal.) NA

Fuel Capacity (gal.) 26.4

GCWR4 (lbs.)13,550

GVWR (lbs.) 8,550

GAWR – Front (lbs.) 4,101

GAWR – Rear (lbs.) 5,360

Wheelbase: 144″

Seating Capacity: 4

Mercedes-Benz® Sprinter Chassis

3.0L 6-cylinder, 188-hp, diesel engine, 5-speed automatic Tip Shift transmission, 220-amp. alternator

On-demand 4WD w/low range electronic stability and traction control

4-wheel ABS brakes

Trailer Hitch4 5,000-lb. drawbar/500-lb. maximum vertical tongue weight

7-pin wiring connector

Optional Equipment

Performance wheels and BF Goodrich® T/A® KO2 all-terrain tires

Galley

Flip-up countertop extension

Laminate countertop

Single burner induction range top w/glass cover

2.5 cu. ft. compressor driven refrigerator/freezer

Stainless steel sink w/folding faucet and glass cover

Cold water filtration system

Pantry

Fold-down exterior table

Pull-up dinette table

Exterior

Side screen door

Rear screen door

Powered patio awning

Porch light w/interior switch

Running boards w/ground effect lighting and rocker trim w/mud guard

Rear mud guards

Movable ladder

Luggage Rack

Heating & Cooling System

Hydronic Heating System

Optional Equipment

13,500 BTU high-efficiency roof air conditioner

Electrical System

AC/DC load center/converter

Auxiliary start circuit

3 deep cycle Group 31 batteries (AGM maintenance free)

Coach battery disconnect system

Dual-battery charge system

30-amp. power cord

Exterior AC receptacles

Exterior DC receptacles

Solar panel battery chargers

2,000 watt AC/DC inverter
